CR-Scan Ferret Pro Review

If you’re looking for a reliable and user-friendly 3D scanner, the CR-Scan Ferret Pro from Creality may be worth considering. The handheld 3D scanner makes converting real-world objects into 3D objects really quick.

The scanner is perfect for hobbyists, makers, and even professionals who need a high-quality and accurate 3D scanner at an affordable price. With a scan size of 150~2000 mm and an accuracy of 0.1 mm, the CR-Scan Ferret Pro delivers accurate and detailed scans with good anti-shake technology and multiple operating modes.

CR-Scan Ferret Pro Review 1

AVAILABLE ON CREALITY

We’ve had the opportunity to test the CR-Scan Ferret Pro and have some thoughts about it.

CR Scan Ferret Pro Review

In this hands-on review, we’ll take a closer look at the scanner and its features. We’ll cover everything, including the setup and scan modes, 3D scanning and show some results. We’ll also compare the CR-Scan Ferret Pro to other similar 3D scanners on the market.

Specifications

Product Name CR-Scan Ferret Pro
Resolution/Point Distance 0.16mm
Working Distance 150~700mm
Frame Rate/Scan Speed up to 30 fps
Scan Size 150~2000mm
Accuracy 0.1mm
Runtime 2.5 hours
Battery Capacity 5000mAh
Single Capture Range 560*820mm
Minimum Scanning 150*150mm
Machine Size 120*30*26mm
Machine Weight 105g
Wireless Connection WiFi6
Operating Systems iOS, Mac, Windows,Android

The CR-Scan Ferret Pro 3D Scanner has an accuracy of 0.1 mm. The scanner has a runtime of 2.5 hours and a battery capacity of 5000mAh. It has a single capture range of 560 × 820 mm and a minimum scanning size of 150 × 150 mm. The machine size is 120 × 30 × 26 mm, and it weighs 105 g. The scanner has wireless connection via WiFi6 and is compatible with iOS, Mac, Windows, and Android operating systems.

What’s in the Box?

The CR-Scan Ferret Pro comes in a beautiful zippered gray carry case. The case protects the 3D scanner during transport and makes it easy to carry.

CR-Scan Ferret Pro Review 2
The Scanner Packaging

The scanner comes fully assembled. There is nothing complicated about the setup. You just have to connect the individual components depending on the operational mode, which can be PC Mode, Wi-Fi Mode, or Smartphone Mode.

Let’s take a look what’s inside. Everything’s laid out very neatly inside the case. The packaging includes not only the 3D scanner but also other accessories that make 3D scanning possible straight out of the box.

CR-Scan Ferret Pro Review 3

Inside the box, you will find:

  • CR-Scan Ferret Pro scanner
  • Battery module
  • Wi-Fi Bridge
  • Tripod
  • Quick Start Guide
  • Connection cables

The included battery can last up to 2.5 hours. This is ample time for you to complete any scanning project. You can use the Wi-Fi bridge for faster data transfer. And if you prefer a hands-free operation, a sturdy tripod is provided.

You can go through the Quick Start Guide to get familiar with the initial scanner setup and operation. All the necessary cables for connection are included.

The 3D scanner is compact and lightweight, and with the zippered box, you can take it wherever you need to go.

With all the necessary components included, you can start scanning right away.

CR-Scan Ferret Pro Setup & Modes

The CR-Scan Ferret Pro has three different modes: PC mode, Wi-Fi mode, and Smartphone mode. The setup process for all modes is simply a matter of combining the modules according to the mode you want to use.

PC Mode

CR-Scan Ferret Pro Review 4
PC Mode

To use the PC mode, connect the 3D scanner to your computer via USB cable and use the Creality scanner software. PC mode is recommended for better scanning performance. This mode is ideal for high-accuracy or high-quality scanning. It also provides faster data transfer speed.

Wi-Fi Mode

In Wi-Fi mode, you can use the Wi-Fi bridge to connect the 3D scanner wirelessly to your smartphone for remote operation. This mode is ideal if you need to scan something outside the reach of your PC or you don’t have a laptop.

CR-Scan Ferret Pro Review 5
WiFi Mode

Smartphone Mode

CR-Scan Ferret Pro Review 6
Smartphone Mode

In Smartphone mode, you can download the dedicated app and use your smartphone as a controller for the scanner directly on the handle. This mode is ideal if you want to use your smartphone as a controller for the scanner.

Creality CR-Scan Ferret Pro Features

Anti-Shake Tracking

This portable 3D scanner has a built-in anti-shake tracking system that ensures accurate and precise scans in any environment. Even when holding the scanner in your hands, the software recognizes the object in a three-dimensional space and continually tracks the movements of your hand. This feature enables capturing 3D models of objects with intricate details and delicate structures in every environment.

Scan Black/Metal Objects Without Spraying

The budget 3D scanner can scan black or metal objects without any need for spraying. If you are familiar with 3D scanning, you know that many other 3D scanners require spraying with a specific powder or coating. With the CR-Scan Ferret Pro, you can skip this step and get straight to scanning. The scanner can capture 3D models of dark or reflective surfaces without you having to alter them in any way.

24-bit Full-Color Scanning

The handheld scanner boasts 24-bit full-color scanning capacity. Therefore, you can capture the true colors of your objects in stunningly detailed and vivid color scans. The feature makes the scanner powerful at capturing vibrant and lifelike models of architecture, art pieces, and other colorful objects.

To have better control of your scan, you can change the surface mode before scanning to focus on either on small geometrical surface features or on color patterns on the object.

High-Quality & Fast Scanning (ASIC Chip)

The CR-Scan Ferret Pro uses an ASIC (Application-Specific Integrated Circuit) chip to deliver high-quality and fast scanning results. This powerful chip enables high precision tracking of objects while also ensuring a higher scanning efficiency.

With an accuracy of 0.1 mm, you can capture even the finest details of your objects with ease. However, you will struggle to get good results if you are scanning small miniatures with fine details.

3D Scanning and Results

The CR-Scan Ferret Pro is a user-friendly 3D scanner that allows for high-quality and accurate scans of objects within seconds. The Creality Scan software makes the scanning process simple for beginners while offering advanced features for more experienced users.

To test the CR-Scan Ferret Pro’s capabilities, we scanned a spray container head. The spray head, which is approximately 7 cm in size and has many intricate details, was the perfect test subject for the scanner. The scanning process was quick and easy, taking just under 2 minutes to produce a high-quality and accurate scan of the head. The details were captured beautifully, and every small feature of the jead was visible.

CR-Scan Ferret Pro Review 7

To compare the scan quality, we 3D printed the. While there were slight differences in the smallest, intricate details, the overall fidelity of the scan remained high. The minor discrepancies were noticeable only if you knew where to look, and from farther away, the printed scan looked almost identical to the original head. This demonstrates that while 3D scanning is not yet a perfect science, it has come a long way and can produce impressive results.

Another object that was scanned was a 3D-printed TMNT bust. Like with the Deadpool bust, the minor differences between the original and the scanned version were in the finer details, which were somewhat smudged in the scanned version. However, these differences were hardly noticeable unless you knew exactly where to look.

CR-Scan Ferret Pro Review 8
Scan
CR-Scan Ferret Pro Review 9
The 3D Printed Bust

The Ferret Pro offers two modes for scanning: color mode and texture mode. Both modes produce high-quality and accurate scans, with the only difference being the level of detail captured. The texture mode captures more detail and will be useful when scanning objects with intricate textures.

The CR-Scan Ferret Pro is a versatile and user-friendly 3D scanner that produces high-quality and accurate scans. While there may be slight differences between the original object and the scanned version, the overall fidelity of the scan remains high. The scanner offers two modes for scanning, both of which produce impressive results.

Creality Scan Software

The Creality 3D scanner software is user-friendly and straightforward. You can use it to create high-quality 3D scans with ease. The software has impressive color texture mapping capability of recreating the colors and patterns of the original objects accurately.

The scanning frame rate is also remarkably high, capturing a comprehensive picture in a fraction of the time compared to other 3D scanners. The software shows real-time footage of the object being scanned. We love its anti-shake tracking feature that ensures high precision scanning, even when handling the 3D scanner is less than steady.

The software has a built-in working distance that makes the scanning process smooth and hassle-free. The colored bar shows you if you are too near or too far from the object. This way, you can be sure your scan will not have holes and every intricate detail will be captured.

After the scanning process is completed, the software offers a straightforward model optimization feature. With the one-click model optimization, you can refine your 3D model, smoothing out any imperfections and improving the overall quality of the scan.

Overall, the Creality Scan Software is an impressive tool that simplifies the 3D scanning process and produces high-quality results with ease. Whether you are a beginner or an advanced user, the software is easy to use and produces excellent results.

CR-Scan Ferret Standard vs. Pro

Considering upgrading to the CR-Scan Ferret Pro? Then, you may be wondering what specific improvements you will get. Below is a brief comparison that will help you make an informed decision.

Enhanced Connectivity and Efficiency

Both the standard and Pro versions of the CR-Scan Ferret are fast and efficient. However, the Pro model comes equipped with WiFi6 technology for faster and more reliable data transfer. This is particularly beneficial in environments with multiple connected devices.

CR-Scan Ferret Pro Review 10
Transferring scan files via WiFi

Simplified Operation

The Pro model boasts a one-click feature that allows you to initiate scans quickly. Thus, the scanner is easier to use and will be particularly beneficial for those who require frequent, hassle-free scanning throughout their workflow.

Extended Runtime

The CR-Scan Ferret Pro offers an increased battery life, providing a runtime of 2.5 hours. This extended duration is ideal for professionals engaged in lengthy scanning sessions or fieldwork.

Advanced Scanning Stability

The Pro model is integrated with an anti-shake tracking feature, which is pivotal in maintaining scan accuracy. This technology ensures the success rate of your scans is substantially higher compared to the standard model, particularly in motion-intensive environments.

Superior Scanning Detail

The CR-Scan Ferret Pro boasts a sophisticated face mapping algorithm that optimizes the camera to capture and produce more detailed and accurate scans. This function is especially useful for applications requiring high-fidelity facial recognition or intricate detail capture.

In summary, both models perform robustly in fast scanning. However, the CR-Scan Ferret Pro is tailored for professionals looking for more efficient, detailed, and reliable scanning experiences. Its advanced features justify the investment, especially for users aiming to leverage improved connectivity, convenience, and detailed capture in their scanning tasks.

CR-Scan Ferret Pro vs. Other 3D Scanners

The CR-Scan Ferret Pro is a standout 3D scanner with its anti-shake tracking feature, high accuracy, and portability. Its compact size and handheld feature allow for easy transportation and scanning of large, delicate objects without risking any damage. With the Ferret Pro, you do not need a static setup with a turntable.

But how does it compare to its competitors on the market? See the table below:

Scanner Anti-Shake Tracking Accuracy Portability Wireless Bridge
CR-Scan Ferret Pro Yes High Highly Portable Yes
CR-Scan Ferret No High Portable No
CR-Scan Lizard No High Portable No
3DMakerPro Lynx No High Portable No
Revopoint POP 3 No Medium Portable No

As you can see on the table above, the Ferret Pro is the only scanner with an anti-shake tracking feature. Therefore, this unit is more accurate than the other scanners. Moreover, it is highly portable, allowing for easy transportation and scanning in different locations.

While phone apps may be cheaper, they lack the functionality and accuracy of a real 3D scanner like the Ferret Pro. In summary, the Ferret Pro is a top choice for those in need of a reliable and portable 3D scanner with high accuracy.

FAQ – Frequently Asked Questions

What’s the difference between CR Ferret and Ferret Pro?

The CR-Scan Ferret Pro is an upgraded version of the standard Ferret model. The Ferret Pro has WiFi6 for faster data handling, one-click scanning for user ease, a longer 2.5-hour battery life, and superior scan stability and detail via anti-shake technology and an advanced face mapping algorithm. The enhancements streamline the scanning process.

Unlike the Ferret, Ferret Pro offers a wireless connection. While Ferret works with some Android phones using a cable, Ferret Pro can connect wirelessly to iPhones and more Android devices. This makes scanning large objects like the human body and outdoor scanning easier.

How accurate is the CR-Scan Ferret Pro 3D scanner?

The Ferret Pro has an accuracy of up to 0.1 mm. This makes it suitable for professional use in industries such as architecture, engineering, and design. It can capture small details on medium- to large-scale objects.

How long does it take to scan an object with the Ferret Pro 3D scanner?

With its one-click scanning feature and advanced face mapping algorithm, the Ferret Pro 3D scanner can capture high-quality scans in just minutes. The exact time may vary depending on the complexity and size of the object being scanned.

Can you 3D scan miniatures with the CR-Scan Ferret Pro?

The Ferret Pro is proficient in capturing larger objects with intricate details. It is not really meant for scanning miniatures. Small details on these tiny models may not be accurately captured and may appear washed out or smoothed over in the resulting scan.

However, at this time, even the best hobby 3D scanners cannot capture tiny features like the eyes or the nose of a war-gaming miniature or something similar in size.

Do I need a Smartphone or App for the CR-Scan Ferret Pro?

No. You don’t need a smartphone to use the CR-Scan Ferret Pro. The scanner has three modes: Smartphone Mode, Wifi + PC Mode, and PC + Cable Mode.

Smartphone Mode utilizes a mobile app to control and interact with the scanner. In contrast, Wifi + PC Mode allows wireless operation with a computer. Finally, PC + Cable Mode caters to users preferring a wired connection for stability.

Can the CR-Scan Ferret Pro be used for outdoor scanning?

Yes, the Ferret Pro can be used both for indoor and outdoor scanning projects as long as there is sufficient lighting in the environment. Its advanced bright sunlight tracking mode allows for high-quality scans even in direct sunlight.

What materials can be scanned with the CR-Scan Ferret Pro?

The Ferret Pro can scan a wide range of materials including plastic, metal, wood, and more.

Do I need scanning spray for some materials with the CR-Scan Ferret Pro?

No. When using the CR-Scan Ferret Pro, you do not have to use a scanning spray, even for materials that are traditionally challenging for 3D scanners. These include shiny and black objects, which are notoriously difficult to scan due to their light-reflecting properties.

In conclusion, the CR-Scan Ferret Pro is a versatile 3D scanner that can be used for a wide range of scanning projects. Its advanced features, such as anti-shake technology and an advanced face mapping algorithm, make it suitable for professional use in various industries. The scanner is easy to use, and it offers multiple modes of operation, including smartphone mode, wifi + PC mode, and PC + cable mode. It can scan a wide range of materials, and it does not require the use of scanning spray even for traditionally challenging materials.

Conclusion – Is the Ferret Pro Finally a Good Hobby 3D Scanner?

Overall, the CR-Scan Ferret Pro is a great choice for hobbyists and professionals alike. Its high accuracy and detail in scans, coupled with its portability and ease of use, make it a valuable tool for those in need of a 3D scanner. The Ferret Pro doesn’t require any special coatings, even for reflective surfaces. It has impressive anti-shake technology and different operating modes.

However, the Ferret Pro is not great for tiny details on objects under the minimum scan size, such as miniatures. This is a common limitation for 3D scanners and not specific to the Ferret Pro.

The Ferret Pro scans with an accuracy of 0.1 mm and has a scan size of 150~2000 mm. It can be handheld and controlled via PC or smartphone.

In terms of comparison, the Ferret Pro is an upgraded version of the standard Ferret and the SE model. The Ferret Pro enhances workflow efficiency with Wi-Fi connectivity, allowing for a cable-free scanning experience.

If you’re in the market for a reliable and user-friendly 3D scanner, the CR-Scan Ferret Pro is definitely worth considering. Its high accuracy and ease of use make it a great option for hobbyists and professionals alike. Just keep in mind its limitations when it comes to scanning tiny details on small objects. If your work will involve such details, you will be better off with the CR Scan Otter.

You can connect with other 3D scanning enthusiasts using the Ferret Pro on Creality’s official Facebook Group here: https://www.facebook.com/groups/creality3dscanner
