8 Differences Between PICASO 3D Designer X and Designer Classic

Wondering what is the difference between the Picaso 3D Designer X and the Designer Classic? This guide provides 8 differences you should know to determine which unit will be suitable for your applications.

In this article, we’ll look at the main differences between the two Picaso 3D printers, that is the Designer X and Designer Classic. After reading this guide, you will know which model will be right for your application.

Let’s get started.

Differences Between Picaso 3D Designer X and Designer Classic

Appearance

This aspect is not so important when choosing a 3D printer. However, we have decided to start with it.

The two Picaso 3D printers differ in color, size, weight and the way the door is opened. For the Designer X, the door opens upwards, while for Designer Classic it opens to the side.

8 Differences Between PICASO 3D Designer X and Designer Classic 1

Filament Feeder and Control System

The Designer X 3D printer filament feed system will detect if the filament is fed unevenly, and may affect the print quality. The system will also pause printing if the plastic runs out or the nozzle clogs. After this, you will receive a message and decide whether to continue printing or not.

The Designer Classic does not have such a systems in the basic configuration.

Calibrating the Print Bed

The Designer Classic is manually calibrated using adjusting screws. This calibration is quite common in 3D printers, but it requires more involvement of the user compared to automatic calibration.

On the other hand, the Designer X has a semi-automatic calibration. Here, you only need to follow the commands on the display to open and close the valves.

Access to Filament During Printing

With the Designer X printer, you can access the filament through the doors on the side. This means you can change the spool while printing.

8 Differences Between PICASO 3D Designer X and Designer Classic 2

On the other hand, the Designer Classic does not allow filament access in such a manner. If the plastic runs out during printing, you cannot put a new spool and continue printing as the lowered print bed with the model will prevent this.

Printer Mechanics

The Designer X has a steel frame mounted on a Z-axis ball screw that moves the platform. This improves structural stability and ensures high print quality.

On the other hand, the 3D printer Designer Classic has simpler mechanics. The body bears the load and is resistant to external influences. The printer has a trapezoidal screw along the Z axis.

Printbed Glass

Both the Designer X and Classic 3D printers have glass on top of the print bed. However, the Classic has regular clamps while the Designer X has magnets and glass pushers for easy installation.

8 Differences Between PICASO 3D Designer X and Designer Classic 3

Air Circulation System

An air circulation system is installed in the Designer X print chamber. Thanks to it, uniform temperature is maintained in the 3D printer. This affects how the filament shrinks.

Unfortunately, the Designer Classic does not have such an option.

Extruder

The basic set of the Designer X comes with Block 400 and a 0.3mm diameter brass nozzle. This allows you to use high-temperature materials when printing. However, for some types of plastics you may need to purchase Block 250.

On the flip side, the Designer Classic has a block 250 and a brass nozzle of 0.5mm diamter. The nozzle is suitable for printing PLA, PETG and others plastics with a melting point of up to 250°C. However, you can purchase a block 400 for the Classic  3D printer to print with high-temperature filaments.

Conclusion

As you can see, there is various differences of the Picaso 3D Designer X and Designer Classic h.

The Designer Classic is a reliable basic 3D printer with a lower price tag and fewer bells and whistles. This is one of the best 3D printers for home use.

On the other hand, the Designer X has a number of advantages, for example, control system and ease of setup and management. In addition to home use, the 3D printer fits perfectly into any enterprise production process, in 3D printing studios and in educational institutions.

Let’s finish this guide by looking at a comparison table showing the features of the Picaso Designer X and the Picaso Designer Classic.

Picaso Designer X vs Picaso Designer Classic: Comparison Table

Designer X Designer Classic
Price CHECK CURRENT PRICE CHECK CURRENT PRICE
Material type ABS, PLA, PETG, Flex, Nylon, PEEK and all materials with temp. extrusion up to 400°С ABS, PLA, PETG, PVA, TPE and all materials with temp. extrusion up to 250°С
Plot area size 200 x 200 x 210 mm 200 x 200 x 210 mm
Number of extruders 1 1
Heating pad temperature Up to 150°С Up to 150°С
Nozzle diameter 0.3 mm 0.5 mm
Extruder operating temperature Up to 410°C Up to 250°С
Connection interface Ethernet, USB Ethernet, USB
Software Picaso 3D Polygon X Picaso 3D Polygon X
Printer weight 17 kg 14 Kg
Printer dimensions 490 x 430 x 390 mm 390 x 390 x 520 mm
Air circulation system Yes No
Glass on the printing platform On magnets Clips
Mechanics Steel frame with ball screws Support body with trapezoidal screw
Access to plastic when printing Yes No
Calibration Semi-automatic manual
Filament feed and presence control system Yes No
